- Стандарты сети
- IPv6; IPv4; WiFi 6 (802.11ax); WiFi 5 (802.11ac); WiFi 4 (802.11n); IEEE 802.11g; IEEE 802.11b; IEEE 802.11a
- Wi-Fi 6 (802.11ax) 5 ГГц
- up to 4804 Mbps
- Wi-Fi 6 (802.11ax) 2,4 ГГц
- up to 1148 Mbps
- Антенны
- External antenna x 8
- Радиотракты
- 5GHz 8x8; 2.4GHz 4x4
- Процессор
- 2.2GHz quad-core processor
- Память
- 256 MB Flash, 1 GB RAM
- Диапазоны Wi-Fi
- 2.4 GHz / 5 GHz
- Режимы работы
- Accesspoint, AiMeshnode, Mediabridge, Repeater, Router
- Порты
- RJ45 for 10Gbps BaseT for WAN/LAN x 1, RJ45 for 1Gbps BaseT for LAN x 8, RJ45 for 1Gbps BaseT for WAN x 1; USB 3.1 Gen 1 x 2; SFP+ x 1
- Кнопки
- WPS Button, Reset Button, Power Button, Wireless on/off Button, LED on/off Button
- Индикаторы
- Power x 1; Wi-Fi x 3; WAN x 1; LAN x 1; 10GE x 1; SFP+ x 1
- Вход питания
- 110V~240V(50~60Hz)
- Выход блока питания
- 19V 3.42A
- Размеры
- 343.64*343.64*80mm
- AiMesh
- AiMesh, • Primary AiMesh Router, • AiMesh Node
- Родительский контроль
- "Allow you to block access to unwanted websites and apps.", Customized Internet Schedule
- Гостевая сеть
- 2.4GHzx3、5GHzx3, Guest Network Connection Time Limit, Guest Network Encryption : Open system, WPA/WPA2-Personal
- Защита сети
- 64, • Maximum Firewall Network Service Filter : 32, • Maximum Firewall URL Filter : 64
- VPN
- VPN Client L2TP, VPN Client Open VPN, VPN Client PPTP, VPN Server IPSec, VPN Server Open VPN, VPN Server PPTP
- WAN
- PPPoE, PPTP, L2TP, Automatic IP, Static IP, Dual WAN, WAN Aggregation, 3G / 4G LTE dongle, Port forwarding, • Maximum Port Forwarding Rule : 64, Port triggering, • Maximum Port Triggering Rule : 32, DMZ, DDNS, NAT Passthrough : PPTP, L2TP, IPSec, RTSP, H.323, SIP Passthrough,PPPoE relay
- LAN
- 64, Wake on LAN (WOL)
- Возможности USB
- FS_Tuxera_HFS+,FS_Tuxera_NTFS,FS_Tuxera_vFAT,FS_ext2,FS_ext3,FS_ext4, Safely Remove Disk, AiCloud, Download Master, AiDisk, Media Server, Time Machine, Samba Server, FTP Server, Shared Folder Privileges
